Welcome Homeowners

Welcome Homeowners

Quality Basement Drainage Products by Grate Products

Welcome Homeowners

Effective June 1, 2016  BasementDepot.com will sell replacement sump pumps, battery back up sump pumps, Santa Fe dehumidifers filters and other basement drainage related products to the public .

Basement & CrawlSpace Contractors

For Information on how you can purchase our FastDrain , GrateDrain, and CrawlShield systems please contact Todd Prosan, our Director Of Contractor Develpoment toddp@grateproducts.com

Grate Products is looking for quality basement waterproofing and crawlspace contractors in limted areas to join our growing network of Healthy Basement  & Crawlspace Contractors. Learn More

French Drain for Health

French Drain for Health

French Drain for Health
Click to enlarge image(s)
Steve Andras spent nearly 7 years traveling and researching the French Drain and how it got it's name. This full color 80 page book explains the early farm drainage techniques in Early America to modern day solutions to solve a wet basement. This book is a must for anyone wanting to operate a basement waterproofing company. This will help a contractor understand not just how to wateproof a basement but more importantly why you would do so. Homeowners will appreciate the easy to read story that really is more than just about a  drain. Read the book and find out why the carved wooden heart (done by Sam Houston in 1854) is on the cover and what does it symbolize.

FastSump 1/3 HP Sump Pump

FastSump 1/3 HP Sump Pump

FastSump 1/3 HP Sump Pump
Click to enlarge image(s)
*GP Favorite Pick: We have tested this pump for over 8 years in our own service department with extraordinary results. This is a very dependable 1/3 hp sump pump. It has a very efficient 4.0 amp motor. Grate Products is listed as the manufacturer and we provide a 3 year warranty (1year manufacturers warranty with free pump replacement for the 2nd and 3rd years)
40 Gallon Per Minute at 10 ft head

(2400 GPH at 10 Ft Head)- compared to a 1/3 hp Zoeller M53 which is 2040GPH)


4.0 amp High Efficient Motor With Upper & Lower Ball Bearings / Runs Cooler & Last Longer
Vortex Impeller / Helps Prevent Clogging
Sealed Entry-Replaceable Power Cord / Easy To Replace In The Field, Prevents Water From Entering The Motor Housing Through A Cut Power Cord (Up To 50’ Available)
Piggy-Back Switch Design / Defective Switches Can Be Diagnosed By Phone; Pump Can Be Operated Manually By Overriding The Switch Every Pump Is Tested In Water /
Ensures That The Pump Meets Head & Flow Requirements

Specifications:
DISCHARGE 1-1/2” NPT. Vertical
LIQUID TEMPERATURE 140 Degrees F. (Intermittent)
MOTOR HOUSING Cast Iron
VOLUTE Cast Iron
SEAL PLATE Cast Iron
IMPELLER Nylon + 30% Fiberglass
SHAFT Nickel Plated Steel
SHAFT SEAL Mechanical
Carbon - Rotating Face
Ceramic - Stationary Face
Buna-N - Elastomer
300 Series Stainless Steel - Hardware
BEARING (UPPER & LOWER) Single Row, Ball, Oil Lubricated
HARDWARE 300 Series Stainless Steel
SQUARE RINGS Buna-N
CORD (UL / CUL) Listed 16 AWG, Type SJTW
10’ Length Standard. Other Lengths Available.
CORD ENTRY Compression Grommet - Outer Jacket Seal
Quick Disconnect Pin Terminals
MOTOR (SINGLE PHASE) 1/3 HP, 1750 RPM, 60Hz
NEMA L Includes Overload Protection In The Motor.
Oil Filled, Class B
Permanent Split Capacitor
WEIGHT 26 lbs Shipping Weight

Warranty: 3 year (1 year full manufacturers warranty, with free pump replacement for year 2 and 3)
FastSump

FastSump

FastSump
Click to enlarge image(s)
Fast Sump is a engineered sump housing that is designed to accept large amounts of water without undermining a foundation. Works with our FastDrain system by using a FastDrain Outlet. Each FastSump includes rubber grommet, permanent mesh filter, dehumidifier plug in cover, slider with wing nut and bolt to hook up a FastDrain Outlet,
